STM32F407IGT6 168MHz Cortex-M4 w/ FPU 1MB Flash 192KB RAM Ethernet Camera IF Cryptographic Acceleration Extensive Timers and Connectivity

STM32F407IGT6 168MHz Cortex-M4 w/ FPU 1MB Flash 192KB RAM Ethernet Camera IF Cryptographic Acceleration Extensive Timers andamp; Connectivity

andnbsp;

Features

andbull; Includes ST state-of-the-art patented technology

andbull; Core: Armandreg; 32-bit Cortexandreg;-M4 CPU with FPU, Adaptive real-time accelerator (ART Accelerator) allowing 0-wait state execution from flash memory, frequency up to 168 MHz, memory protection unit, 210 DMIPS/ 1.25 DMIPS/MHz (Dhrystone 2.1), and DSP instructions

andbull; Memories

andnbsp; andndash; Up to 1 Mbyte of flash memory

andnbsp; andndash; Up to 192+4 Kbytes of SRAM including 64 Kbyte of CCM (core coupled memory) data RAM

andnbsp; andndash; 512 bytes of OTP memory

andnbsp; andndash; Flexible static memory controller supporting Compact Flash, SRAM, PSRAM, NOR and NAND memories

andbull; LCD parallel interface, 8080/6800 modes

andbull; Clock, reset, and supply management

andnbsp; andndash; 1.8 V to 3.6 V application supply and I/Os

andnbsp; andndash; POR, PDR, PVD and BOR

andnbsp; andndash; 4-to-26 MHz crystal oscillator

andnbsp; andndash; Internal 16 MHz factory-trimmed RC (1% accuracy)

andnbsp; andndash; 32 kHz oscillator for RTC with calibration

andnbsp; andndash; Internal 32 kHz RC with calibration

andbull; Low-power operation

andnbsp; andndash; Sleep, Stop, and Standby modes

andnbsp; andndash; VBAT supply for RTC, 20andtimes;32-bit backup registers + optional 4 KB backup SRAM

andbull; 3andtimes;12-bit, 2.4 MSPS A/D converters: up to 24 channels and 7.2 MSPS in triple interleaved mode

andbull; 2andtimes;12-bit D/A converters

andbull; General-purpose DMA: 16-stream DMA controller with FIFOs and burst support

andbull; Up to 17 timers: up to twelve 16-bit and two 32 bit timers up to 168 MHz, each with up to 4 IC/OC/PWM or pulse counter and quadrature (incremental) encoder input

andbull; Debug mode

andnbsp; andndash; Serial wire debug (SWD) andamp; JTAG interfaces

andnbsp; andndash; Cortex-M4 Embedded Trace Macrocellandtrade;

andbull; Up to 140 I/O ports with interrupt capability

andnbsp; andndash; Up to 136 fast I/Os up to 84 MHz

andnbsp; andndash; Up to 138 5 V-tolerant I/Os

andbull; Up to 15 communication interfaces

andnbsp; andndash; Up to 3 andtimes; I2C interfaces (SMBus/PMBus)

andnbsp; andndash; Up to 4 USARTs/2 UARTs (10.5 Mbit/s, ISO 7816 interface, LIN, IrDA, modem control)

andnbsp; andndash; Up to 3 SPIs (42 Mbits/s), 2 with muxed full-duplex I2S to achieve audio class accuracy via internal audio PLL or external clock

andnbsp; andndash; 2 andtimes; CAN interfaces (2.0B Active)

andnbsp; andndash; SDIO interface

andbull; Advanced connectivity

andnbsp; andndash; USB 2.0 full-speed device/host/OTG controller with on-chip PHY

andnbsp; andndash; USB 2.0 high-speed/full-speed device/host/OTG controller with dedicated DMA, on-chip full-speed PHY and ULPI

andnbsp; andndash; 10/100 Ethernet MAC with dedicated DMA: supports IEEE 1588v2 hardware, MII/RMII

andnbsp;

Applications

Industrial Automation and Control andndash; Such as PLCs, motor drives, industrial networks, and human-machine interfaces (HMI).

Medical and Healthcare Equipment andndash; Including patient monitors, diagnostic devices, and portable medical instruments.

Consumer Electronics and IoT andndash; Used in high-end smart home appliances, IoT gateways, and audio processing systems.

Automotive and Transportation andndash; Applicable in body control systems, infotainment subsystems, and fleet management terminals.

Image Processing and Video Applications andndash; Supports barcode scanners, basic machine vision, and surveillance system data acquisition.

andnbsp;

Description

The STM32F405xx and STM32F407xx family is based on the high-performance Armandreg; Cortexandreg;-M4 32-bit RISC core operating at a frequency of up to 168 MHz. The Cortexandreg;-M4 core features a floating-point unit (FPU) single precision which supports all Arm single precision data-processing instructions and data types. It also implements a full set of DSP instructions and a memory protection unit (MPU) which enhances application security.

The STM32F405xx and STM32F407xx family incorporates high-speed embedded memories (flash memory up to 1 Mbyte, up to 192 Kbytes of SRAM), up to 4 Kbytes of backup SRAM, and an extensive range of enhanced I/Os and peripherals connected to two APB buses, three AHB buses and a 32-bit multi-AHB bus matrix.

All devices offer three 12-bit ADCs, two DACs, a low-power RTC, 12 general-purpose 16-bit timers including two PWM timers for motor control, two general-purpose 32-bit timers. a true random number generator (RNG). They also feature standard and advanced communication interfaces.

andbull; Up to three I2Cs

andbull; Three SPIs, two I2Ss full duplex. To achieve audio class accuracy, the I2S peripherals can be clocked via a dedicated internal audio PLL or via an external clock to allow synchronization

andbull; Four USARTs plus two UARTs

andbull; A USB OTG full speed and a USB OTG high speed with full-speed capability (with the ULPI)

andbull; Two CANs

andbull; An SDIO/MMC interface

andbull; Ethernet and the camera interface available on STM32F407xx devices only
